New Bungalow, Bubble Sale V1 Reinforced Series, 4 meters

Original price was: $3,846.00.Current price is: $2,846.00.

Material: Sandwich panels
Insulation: Rigid polyurethane foam
Wall thickness: 50 mm
Roof thickness: 40 mm
Roof covering: Galvanized steel sheet with Greek corrugations
Wall color: Light grey RAL 9002

... people are viewing this right now

Guaranteed Safe Checkout

New Bungalow Bubble Sale V1 4 meters

The Sales Bubble bungalow allows you to have a comfortable and aesthetically pleasing office or sales space at an unbeatable price and in a timeframe unmatched by traditional construction solutions. We have standardized four sales bubbles with different sizes and levels of options.

Our 4-meter V1 sales bubble is offered as standard in our “Reinforced” series.

The “Reinforced” series bungalows are modules with a reinforced structure and improved thermal and acoustic insulation (thick insulation and double glazing). They offer greater user comfort compared to the standard series, making them more suitable for use in applications such as offices.

If you would like this same module with the most reinforced structure available in our range, or the most efficient thermal and acoustic insulation, you can request a quote for this bungalow in our “Isoplus” series.

Our “Sales Bubble V1” bungalow requires an 8-week manufacturing and delivery time . For a faster turnaround with a similar configuration, please consider our “Sales Bubble 6-meter V2” series bungalow (available only in 6 meters).

Our bungalows are assembled in France.

Technical specifications

DIMENSIONS

External height: 252 cm
Interior height: 220 cm
Length: 409 cm
Width: 242 cm

FRAMEWORK

Material: Galvanized and lacquered steel
Colour: Anthracite grey RAL 7016
Thickness: 2 mm
Base: height 160 mm
Roof: height 200 mm
Handling: 4 lifting points on the roof for lifting hooks and forklift pockets in the base for handling with a forklift

WALLS AND ROOF

Material: Sandwich panels
Insulation: Rigid polyurethane foam
Wall thickness: 50 mm
Roof thickness: 40 mm
Roof covering: Galvanized steel sheet with Greek corrugations
Wall color: Light grey RAL 9002

FLOOR

Structure: Water-resistant chipboard panels
Thickness: 18 mm
Flooring: PVC imitation parquet with black baseboards

JOINERY

Material: White lacquered aluminum RAL 9010
Door(s): 1 solid entrance door, dimensions 104 x 220 cm (90 cm opening)
Window(s): 2 fixed glazed bay windows, dimensions 174 x 220 cm, clear laminated safety glass, 4+4 mm thick

ELECTRICITY

Lighting: 1 LED neon tube
Outlets: 2 power outlets
Heating: 1 x 1500W convector heater
Table: 1 table including residual current device and circuit breakers
Connection: 1 outdoor junction box

Possible options

Free choice of colors for the frame: white RAL 9010, light grey RAL 9002 or anthracite grey RAL 7016
Other colors are available as options for the panels, frame or joinery.
Underfloor insulation made of 50mm thick glass wool on galvanized steel protective sheets
With a ceiling height of 2.40 m, the door remains at a height of 2.20 m.
Foundation on skids (2 16 cm ipe beams)
Integrated WC area with toilet + hand basin + door + partitions (hot water at the sink can be added as an extra)
Integrated shower area (with hot water) + door + partitions
4 rainwater downpipes
Joinery in anthracite grey lacquered aluminium RAL 7016
UNICO R10 2300W Reversible Air Conditioner
Window air conditioner, cooling only, 12000 BTU
SHINY 12 Reversible Portable Air Conditioner R290 3.5 KW + Window Kit
LED panels instead of fluorescent tubes
Additional semi-glazed door, solid door, or fully glazed door
Additional window, bay window, snack bar window or window with counter and intercom
Roller shutters in aluminium or PVC, specific colours available
Wood-concrete flooring, 16 mm thick, instead of chipboard (essential if the bungalow is not raised a few centimeters by blocks or shims, and also for humid environments) load capacity: 400 kg/m²
18mm thick phenolic wood flooring instead of chipboard, load capacity: 500 kg/m²
Heavy-duty PVC flooring instead of PVC imitation parquet or tile flooring
Smooth panels, food-grade panels, rock wool panels, or fire-resistant panels
Additional sockets or RJ45 sockets
